Sound Heat Insulation Precast Concrete Wall Panels / Sandwich Board

Large Image : Sound Heat Insulation Precast Concrete Wall Panels / Sandwich Board

Product Details:

Place of Origin:	China
Brand Name:	Vanjoin
Certification:	CE, BV, ISO
Model Number:	VJ-WP-AY009

Payment & Shipping Terms:

Minimum Order Quantity:	300m2
Price:	negotiation
Packaging Details:	Standard Exporting Pallet Packing, 18 Pallets per 20ft Container
Delivery Time:	7 work days
Payment Terms:	T/T, L/C
Supply Ability:	200,000m2 per Month

Detailed Product Description

Usage:	Mainly For Interior And Exterior Wall	Application:	Villa, School, Ofiice
Advantages 1:	Green, Without Asbestos	Advantage 2:	Heat Insulation, Sound Insulation
Advantage 3:	Firerproof, Waterproof	Advantage 4:	Durable, Long Lifespan
Length:	2270mm	Width:	610mm
Thickness:	60mm, 75mm, 90mm, 100mm, 120mm, 150mm

Sound Insulation Precast Concrete Wall Panels Heat Insulation Sandwich Board

1. Composition

Face board, both sides are 5mm calcium slicate board

Core materials are eps foam, cement,sand, additives.

2. Installation Accessories

Cement mortar, connecting wall panels

Steel bar, fix wall panels

Fiberglass mesh, base layer for wall anti-cracking

Anti-crack mortar, basic adhesive for wall anti-cracking

3. Installation Tools

Electrical cutter

Electrical hammer

Trowel

Level instrument

Level ruler

Measuring tape

Hammer

4. Installation Process

1). Setting the line and carring the board in position

2). Sawing board

3). Sizing, sizing cement mortar on the side of panels

4). Installation, carry panel, correct panel and fix panel

5). Correcting and fixing

6). Grouting and filling starch

7). Sticking fiberglass mesh

8). installing electricity wire and switches

9). Installing doorcase

10). Facing coating and wall papers

11). Facing flexible soft ceramic tile

12). Electric apparatus installation

5. Advantages

Lightweight	1 person can carry panel easily
Eco-friendly	100% non-asbestos
Fast Construction	3 workers can install 60-80m2 per day
Strong,Durable and Long Lifespan	70 years
Sound Insulation	42-46 dB
Windproof	65m/s
Fireproof	4 hours
Anti-earthquake	Grade 8-9
Best hanging force	Single point hanging force is 50kg
Weight capacity	650KG / square meter

6. Specification and Weight and Loading Information

Name	Size(LWT)MM	Weight(KG)	Loading(PCS/M2 per 20ft)
Fast Installation Composite Panel Board Durable Sandwich Wall Panel	227061060	45-48	315 pcs / 436
	227061075	50-53	252 pcs / 349
	227061090	55-58	207 pcs / 287
	2270610100	60-65	189 pcs / 262
	2270610120	65-75	153 pcs / 212
	2270610150	90-90	126 pcs / 175
