150mm High Strength EPS Cement Sandwich Panel Prefab House Prefabricated Wall Building Consruction Material

Large Image : 150mm High Strength EPS Cement Sandwich Panel Prefab House Prefabricated Wall Building Consruction Material

Product Details:

Place of Origin:	China
Brand Name:	Vanjoin
Certification:	CE, BV, ISO
Model Number:	VJ-WL-WP-53

Payment & Shipping Terms:

Minimum Order Quantity:	1X20GP Container free sample available
Price:	negotiation
Packaging Details:	1. Free packing ( with normal pallet and normal packing belt ) 2. Standard exporting packing ( wraped with plastic film , edge protect and good pallet )
Delivery Time:	7~10 working days after receive payments
Payment Terms:	L/C,T/T,Western Union, D/A,D/P, MoneyGra
Supply Ability:	200000 Square Meter/Square Meters per Mont

Detailed Product Description

Color:	Grey	Panel Material:	Nonmetal
Use Life:	70Years	Fireproof:	240 Minutes – Class A
Waterproof:	Good	Hanging Force:	More Than 50KG
Feathures:	Fast Construction, Anti-earthquake, Light Weight, Save Space

1.Specification,Usage & Loading details

Length *Width*Thickness ( 2270---3000)mm*610mm*(60,75,90,100,120,150,180mm)

Specification ( Length WidthThikcness )	Loading on 20ft (pcs/m2)	Usage of Different Thickness
2270mm610mm60mm	315pcs / 436 m2	Internal wall & Roof
2270mmx610mmx75mm	252pcs/ 349 m2	Internal wall
2270mmx610mmx90mm	207pcs/ 287 m2	Internal wall
2270mmx610mmx100mm	189pcs/ 262 m2	Internal & External wall
2270mmx610mmx120mm	153pcs/ 212 m2	External wall
2270mmx610mmx150mm	126pcs/ 175m2	External wall

2 .Composition:

Core materials: cement, EPS, and fly ash or sand core

Surface materials: Calcium Silicon Board , Fiber Cement Board , Mgo Board etc

3. Application of EPS Wall Panel:

1) Floor System

Vanjoin light weight compound sandwich panel can be innovatively used as floor board.

This system has the outstanding advantages such as high load-bearing capacity, anti-static electricity,

friction resistance, high strength, convenient for wire groove and water pipe inbuilt, corrosion resistance,

no deformation, no split, etc.

2) Roof System

This system not only solves the problem of roof leakage, but also has the advantages such as heat insulation, neat joint surface, high temperature resistance, etc.

3) Interior Partition System

With EXCELLENT fireproof, best hanging force, sound insulation, heat insulation, waterproof, easy installation and the like characteristics.

150mm High Strength EPS Cement Sandwich Panel Prefab House Prefabricated Wall Building Consruction Material

4) Exterior Wall System

4. Advantages Of Vanjoin Sandwich Wall Panel

Light weight	1 person can take up two pieces of vanjoin panel
Energy-saving, Eco-friendly	100% non-asbestos
Strong and durable	Long life 60-70 years
Heat insulation and preservation	Thermal conductivity: 0.221W/mk
Sound insulation	42-46 DB
Weatherproof; windproof	70m/s; grade 13
Fireproof	Our sandwich wall panel can keep well under 1000 degree temperature about 4 hours
Anti-impact, anti-earthquake	Grade 8
Best hanging strength	Single point hanging force is > 1200 N
Load bearing capacity	Over 50 kg
