Product Details:
Payment & Shipping Terms:
|
| Raw Material: | EPS, Sand/fly Ash, Cement, Additives | Size (L*W*T): | 2270mmx610mmx60mm(75,60,100,120,150) |
|---|---|---|---|
| Face Material: | Calcium Silicon Board | Screw Pull Out Test: | Tonf 0.1935 |
| Anchorage Load: | 50kg | Heat Resistance: | 80 C |
| Fireproof: | 4 Hours --A Class | Anti-earthquake: | 8-13 Grade |
| Useful Life: | 50-60 Years |
100mm Lightweight Fireproof Sound Insulation EPS Cement Sandwich Panel for High Buildings
1 . Description
Lightweight EPS Cement Sandwich wall panel for board is a kind of light weight energy-saving green compound board material taking fiber reinforced calcium silicon board or cement calcium silicon board as panel, with cement ,EPS, fly ash as fillers and forming by one time compound .It can widely be applied to wall materials of various high and low building, such as: bank, office building, hospital,school, hotel, mall, amusement hall, active barrack, old house reconstruction, residence and workshop .
Composition :
Usage :
Interior and exterior partition on steel or concrete structure building, for new construction, additions or renovations. Roof and floor system ,but it need steel frame .
Advantages :
2 . Specifications :
|
Name |
Size(L*W*T)mm |
Weight (kg/m2) |
Packing(pcs/m2 20’GP) |
Application |
|
EPS Cement sandwich wall panel
|
2270x610x60 |
45-48 |
315 pcs /436 m2 |
Roof, interior wall |
|
2270x610x75 |
50-53 |
252pcs / 349 m2 |
Interior wall |
|
|
2270x610x90 |
55-58 |
207pcs / 287 m2 |
Interior/exterior wall |
|
|
2270x610x100 |
60-65 |
189pcs / 262 m2 |
Interior/exterior wall |
|
|
2270x610x120 |
65-75 |
153pcs / 212 m2 |
Exterior wall |
|
|
2270x610x150 |
80-90 |
126pcs / 175 m2 |
Exterior wall |
3 . Technical Data :
|
|
Item |
National Standards |
Testing Results |
||||
|
60mm |
90mm |
120mm |
60mm |
90mm |
120mm |
||
|
1 |
Anti-impact performance/times |
≥5 |
≥5 |
≥5 |
≥6 |
≥6 |
≥10 |
|
2 |
Anti-bending damage load/times over deadweight |
≥1.5 |
≥1.5 |
≥1.5 |
≥3 |
≥3 |
≥3 |
|
|
Anti-pressure strength /Mpa |
≥3.5 |
≥3.5 |
≥3.5 |
≥6 |
≥6 |
≥6 |
|
|
Surface density kg/m2 |
≤70 |
≤90 |
≤110 |
≤45 |
≤54 |
≤66 |
|
5 |
Single point hanging Strength /N |
≥1000 |
≥1000 |
≥1000 |
≥1000 |
≥1200 |
≥1300 |
|
6 |
Fire proof limit /h |
≥1 |
≥1 |
≥1 |
≥3 |
≥3 |
≥4 |
|
7 |
Sound insulation capacity in the air /Db |
≥30 |
≥35 |
≥40 |
≥35 |
≥40 |
≥45 |
|
8 |
Soften coefficient |
≥0.80 |
≥0.80 |
≥0.80 |
≥1 |
≥1 |
≥1 |
|
9 |
Moisture rate a/% |
≤12 |
≤10 |
≤10 |
≤10 |
≤9 |
≤7 |
|
10 |
Heat transfer coefficient w/m2.k |
≤2.0 |
≤2.0 |
≤2.0 |
≤1.0 |
≤0.6 |
≤0.5 |
|
11 |
Drying shrinkage /mm/m |
≤0.6 |
≤0.6 |
≤0.6 |
≤0.45 |
≤.0.5 |
≤0.5 |
|
12 |
Inner radiation index |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
|
13 |
Outer radiation index |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
|
14 |
Radioactivity Limit |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
≤1 |
4 . FAQ :
1 ). How many years your company has been in this field?
VANJOIN : More than 10 years of manufacturing EPS concrete sandwich wall panel,
now we are TOP 1 In middle of China, and among top 2 in china in this field .
2 ). Where is your main market of VANJOIN?
VANJOIN : Main market Asia, South America, Africa,South East Asia is our largest market,
Mid East is our second largest market.
3 ). Exporting details :
VANJOIN : Loading & shipping 400 x 20 GP each month.
4 ). More information of VANJOIN factory?
VANJOIN : land area 30,000 m2 machines, full-automatic production line Productivity:
2,000,000 m2 wall panel per year.
5 ). How could i get the samples?
VANJOIN : We will send you the free samples, catalogues, CD, but the Express charge is required.
If you have the DHL, TNT, UPS, FedEx account, this is the best.
If not, you can transfer money to our Western Union or Paypal, then we will send you.
5 . Package
