Product Details:
Payment & Shipping Terms:
|
| Product Name: | 100MM Fireproof Polyurethane House Exterior Eps Sandwich Wall Panel Factories Lightweight | Surface Panel: | Calicium Silicon Board |
|---|---|---|---|
| Specification(L*W*T): | 2270*610*60/75/90/100/120/150mm | Core Material: | EPS, Cement, Sand, Water, Additive, Etc |
| Advantages: | Waterproof, Fireproof, Sound Insulation, Heat Insulation Panel | Fireproof: | Under 1000 Degree For 4 Hours Without Damage To The Wall |
| Service Life: | 60-70 Years | Anti-earthquake: | Class 8 |
Fireproof polystyrene building panels House Exterior eps concrete panel Lightweight
※ 1. Composition of House Exterior Eps Sandwich Wall Panels:
| Products Name: | House Exterior Eps Sandwich Wall Panels |
|
Sandwich Panel Core materials: |
(100% non-asbestos, asbestos free), Water, cement, EPS, Sand and additives. |
| Usage: |
Roof, floor, interior wall, innner wall, internal wall, partition wall, exterior wall, outer wall, external wall; |
| Specification: | 2270mm*610mm*60/75/90/100/120/150mm; |
| Advantages: |
Lightweight, Fast Construction, Waterproof, Fireproof, Sound and Heat Insulation |
| Double Sides Surface Board: |
Calcium silicate board 5.0mm thickness; Fiber reinforced cement board, FRC board |
| Joining Method: | Tongue & Groove Type, Interlock Type |
| Thermal Conductivity: | 0.221W/mK |
| Service Life: | 60-70 Years |
| Certificates: |
CE, BV, ISO9001, ISO14000, , STC, Invention Patent |
※ 2. Specification of House Exterior Eps Sandwich Wall Panels:
• Thickness: 60, 75, 90, 100, 120, 150mm
• Width: 610mm
• Length: 2270mm (custom-made length can be made for volumn order)
| Name | Specification | Weight (kg/m2) |
Packing(pcs/m2 per 20’GP) |
Application |
|
VJ Lightweight
Compound
Sandwich Panel |
2270*610*60 | 45~48 | 315pcs/436m2 | Roof system |
| 2270*610*75 | 50~53 | 252pcs/349m2 | Floor system | |
| 2270*610*90 | 55~58 | 207pcs/287m2 | Interior/Exterior wall | |
| 2270*610*100 | 60~65 | 189pcs/262m2 | Interior/Exterior wall | |
| 2270*610*120 | 65~75 | 153pcs/212m2 | Exterior wall | |
| 2270*610*150 | 80~90 | 126pcs/175m2 | Exterior wall |
Remark: All kinds of House Exterior Eps Sandwich Wall Panels can be customized by customers' specific requirement, such as density and length of panel.
※ 4. Features and Advantages of House Exterior Eps Sandwich Wall Panels:
House Exterior Eps Sandwich Wall Panels is fire proof, heat insulation, sound insulation, waterproof, windproof, anti-impact, anti-seismic.
House Exterior Eps Sandwich Wall Panels is light weight, energy saving, space saving, eco-friendly, weathering resistance, good resistance to freezing, thawing and ageing.
House Exterior Eps Sandwich Wall Panels is strong and durable, long life span. It has great load bearing & hanging force for TV, air conditioner, panel board, splitter box, cabinet, closet, etc.
Concrete Fireproof Heat Insulation Sandwich Wall Panels is easy installation, fast construction, easy decoration, easy pre-bury for water pipe, electric wire, concealed wire, switch, etc.
| Interior/Exterior Sandwich Panel | Fast construction | 75-80m2/day three workman |
| Sound insulation | 46dB | |
| Space saving | Save 4.26m2 per 100 m2 area | |
| Anti-seismic | Class 7-8 | |
| Fireproof | 4 hours, under 1000 degree centigrade | |
| Eco-friendly | 100% non-asbestos | |
| Hanging force | Single point hanging force 50kg, Embed hanging force 150kg | |
| Service Life | 60-70years |
