Product Details:
Payment & Shipping Terms:
|
| Features: | Fast Construction, Anti-earthquake, Light Weight, Save Space | Product Name: | Sandwich Wall Panel Material EPS Cement Insulation Board |
|---|---|---|---|
| Core Material: | EPS, Cement, Sand / Flyash, Water, Additive, Etc | Size: | 2270*610mm |
| Usage: | Exterior Wall, Interior Wall | Soundproof Performance: | 38~46dB |
| Fire Resistant: | At Least 120 Minutes | Service Time: | 60-70 Years |
Nonmetal Sandwich Wall Panels Material EPS Cement Insulation Board
Advantages of Sandwich Wall Panel Material EPS Cement Insulation Board:
1. Most Area-saving. In comparison of the inner wall panel 75mm abd 120mm, every 12m will increase practical area, for the 100㎡ house, it will increase 4.26㎡.
2. Most light weight, just sixth of the brick building
3. Most fire-proof. Under 1000 degree centigrade for 240 minutes, there isn't damage to the wall.
4. Most waterproof and dampproof. Because of the special featuresof the solid panel, the feature of waterproof and dampproof is very obvious. The experiment shows that without any waterproof facing, build one pool with our products, and fill it with water, the back of the wall can keep dry without ant blot.When in damp weather, there isn't any condensation wate.
5. Most sound-insulation. 46dB-50dB sound-insulation effect, accord with the national standard GBJ121-88.
6. Most anti-seismic and inpact resistance. Earthquake resistant level: M8.0
7. Best hanging strength. Expansion bol can be installed in random part of the wall, the point hanging force can reach more than 50kg(50-70kg). With other Pre-embedded material in the panel, the strength can reach 150kg
8. Most civilized, environmental, high efficiency construction
Simple construction and transportation, stacking health, dry operation, no sludge, low loss, less waste, construction convenient, no bricklaying plastering, shorten the construction period, slotted fast, easy to install water and electricity pipeline. The construction efficiency is 8-10 times of the normal masonry, it's a kind of high-quality reusable wall.
Product Performance of Sandwich Wall Panel Material EPS Cement Insulation Board:
|
Light weight |
1 person can take up two pieces of vanjoin panel |
|
Energy-saving, Eco-friendly |
100% non-asbestos |
|
Easy to install, fast construction |
3 workers can finish a 160 m2 house just by 1 day |
|
Strong and durable |
Long life 60-70 years |
|
Sound insulation |
38-46 DB |
|
Weatherproof; windproof |
70m/s; grade 13 |
|
Fireproof |
Our sandwich wall panel can keep well under 1000 degree temperature about 4 hours |
|
Anti-impact, anti-earthquake |
Grade 8 |
|
Best hanging strength |
Single point hanging force is > 1200 N |
|
Weight capacity |
400KG / square meter |
Packaging & Shipping of Sandwich Wall Panel Material EPS Cement Insulation Board:
|
Specification (mm) |
Weight (kg/m2) |
Packing |
|
2270x610x60 |
45~48 |
315pcs, 436m2 |
|
2270x610x75 |
50~53 |
252pcs, 349m2 |
|
2270x610x90 |
55~58 |
207pcs, 287m2 |
|
2270x610x100 |
60~65 |
189pcs, 262m2 |
|
2270x610x120 |
65~75 |
153pcs, 212m2 |
|
2270x610x150 |
80~90 |
126pcs, 175m2 |
Application of Sandwich Wall Panel Material EPS Cement Insulation Board:
For interior and exterior wall partition on steel or concrete structure building, new construction or renovations. It can replace construction materials such as block, wire spatial grid structure perlite board, perlite porous board and etc. It can widely be applied to wall materials of various high and low buildings such as bank, office building, hospital, school, hotel, mall, amusement, old house reconstruction, residence and workshop.
