Product Details:
Payment & Shipping Terms:
|
| Product Name: | Eco-friendly Sound Insulation Fireproof Modern Prefab Houses Villa System | Villa Structure: | No Structure, Steel Structure, Concrete Structure |
|---|---|---|---|
| Wall Material: | Eps Cement Sandwich Wall Panels | Roof Material: | Eps Sandwich Panels |
| Villa Design: | Available | Villa Layout: | Available |
| Installation Tools: | Electrical Cutter, Electrical Hammer, Trowel, Level Instrument, Level Ruler, Measuring Tape, Hammer | Villa Accessories: | Kictchen, Toilet, Bedroom, Bath Room, Living Room, Doors, Windows, Lights, Etc |
Eco-friendly Sound Insulation Fireproof Modern Prefab Houses Villa System
1. What Can You Get From Vanjoin
Professional guidance;
Novel design;
Villa layout;
Material calculation;
Premium sandwich panels;
One-stop shopping
Vanjoin light weight compound sandwich panel can automatically adjust indoor air and water content with the season and climate changes, which can keep the temperature at an invariable temperature level, and such ecology effect just goes with tide of modern residential building.
2. Villa Features
|
|
Advantages |
Features |
|
1 |
Seismic resistance rate |
Grade 8 |
|
2 |
Wind load |
Grade 13 |
|
3 |
Fast and easy construction |
75 sqm house can be finished by 3 person within 1 day |
|
4 |
Long service life |
60-70 years |
|
5 |
Heat insulation |
Advanced heat insulation and perservation mode |
|
6 |
Eco-friendly |
Asbestos free |
|
7 |
Excellent sound proof |
46dB |
|
8 |
Fireproof, Waterproof |
Excellent |
|
Custom-made service is provided. |
||
3. Villa System
Windproof;
Sound insulation;
Energy-saving;
Area-saving:
Waterproof, damp proof;
Fireproof;
Best hanging force;
Anti-seismic and impact resistance;
Long life span and easy embedding;
Most civilized, environmental, high efficiency.
4. Villa Structures
No Structure;
Steel structure;
Concrete structure
5. Installation Tools
Electrical cutter, Electrical Hammer, Trowel, Level Instrument, Level Ruler, Measuring Tape, Hammer
6. Villa Accessories
Kictchen, Toilet, Bedroom, Bath Room, Living Room, Doors, Windows, Lights, etc
7. Installation Process
According to wall line, switch box line, pipe position line and cutting groove to install wall panels, wirings, switches and water system, the installation is completed with mortar filling;
Scraping putty directly without plastering on the installed wall, then brushing coating and hanging wall paper;
Paving ceramic tiles or other wood facing panels casually without plastering on installed walls;
Light steel keel ceiling series, convenient and quick.
Vanjoin panel is formulated without asbestos or sepiolite or any inorganic fibres.
When using powder saws or sanders in a confined space, dust extraction equipment is recommended to control the dust levels.
8. House Details
| No | Items | Unit |
Remarks | ||
| Ⅰ:House Body: | |||||
| 1 | Interior Wall | m2 | 2270*610*90mm light weight EPS sandwich wall panel | ||
| 2 | Exterior Wall | m2 | 2270*610*120mm light weight EPS sandwich wall panel | ||
| 3 | Roof | m2 | 2270*610*60mm light weight EPS sandwich wall panel | ||
| 4 | Roof | m2 | Chain tiles | ||
| 5 |
Roof waterproof factice |
barrel | Professional waterproof processing for roof | ||
| 6 | Steel Structure | T | Dedicated Steel Structure for panel | ||
| 7 | Decoration Pillar | pc | Steel structure processing for decoration pillar | ||
| 8 |
Window (1200mm*1200mm) |
set | Plastic steel structure, vacuum glass | ||
| 9 |
Window (500mm*1200mm) |
set | Plastic steel structure, vacuum glass | ||
| 10 |
Door (700mm*2000mm) |
set |
Finished wooden door including door pocket,door lock and other accessories |
||
| 11 |
Door (800mm*2000mm) |
set |
Finished wooden door including door pocket,door lock and other accessories |
||
| 12 |
Door (860mm*2050mm) |
set |
Finished entrance door including door pocket,door lock and other accessories |
||
| 13 |
Door (960mm*2050mm) |
set |
Finished entrance door including door pocket,door lock and other accessories |
||
| Ⅱ:Housing decoration material | |||||
| 1 | Electrical | m2 | 1.5,2.5,4 single strends of cooper heart ( pvc pipe) | ||
| 2 |
Water supply and drainage |
m2 | PP-R waterpipe ( water supply /cold water/hot water ) Drainage waterpipe (pvc50-110) |
||
| 3 |
Latex Paint (interior wall) |
m2 | White latex paint (surface paint) | ||
| 4 |
Latex Paint (exterior wall) |
m2 | |||
| 5 |
Putty Powder (interior wall) |
bag | basic processing for latex paint | ||
| 6 |
Putty Powder (exterior wall) |
bag | |||
| 7 |
Plaster (interior wall) |
bag | |||
| 8 |
Ceiling (interior) |
m2 | light steel keel , 9mm gympssum board | ||
| 9 |
Ceiling (exterior) |
m2 | calcium silicate board | ||
| 10 | Floor tiles | m2 | 600mm*600m floor tiles | ||
| 11 | Floor boards | m2 | Laminate flooring (including baseboard, moisture-proof pad) | ||
| 12 |
Floor tiles (bathroom) |
m2 | Anti-skid white floor tiles 300mm*300m | ||
| 13 |
Ceiling (bathroom) |
m2 | 300mm*300mm Aluminum plate square, grossroots light keel | ||
| 14 |
Ceiling edge article (bathroom) |
m | |||
| 15 |
Wall tiles (bathroom, kitchen) |
m2 | 300mm*450mm Brand Lustre wall tiles | ||
| 16 | Toliet | pc | Brand ceramic product | ||
| 17 | Bathroom cabinet | set |
PVC cabinet800mm, ceramic table, including mirror,water mixing valve,etc. |
||
| 18 | shower head | pc | common type single sprinkle,common water mixing valve | ||
| 19 | Floor drain | pc | Finished Copper product | ||
| 20 | Triangle valve | pc | Finished Copper product | ||
| 21 | PAP | pc | Finished Copper product | ||
| 22 | quick-opening | pc | Finished Copper product | ||
| 23 | kitchen cabinet | M |
UV front plate,artificial stone table-board,including top counter,bottom counter, hardware handles. |
||
| 24 | wash basin(kitchen) | pc | Finished stainless steel product | ||
| Ⅲ:Installation Accessories | |||||
| 1 | PU foam | bottle | Filling in the window and door | ||
| 2 |
Polyurethane foam cleaner |
bottle | clear the gun | ||
| 3 |
Polyurethane foam shooting guns |
pc | used for pu foam | ||
| 4 | steel bar | pc | Contacting the wall panels | ||
| 5 | Cement Mortar | m2 | Contacting the wall panels | ||
| 6 | Glass glue | pc | used for fixing in wash room | ||
| 7 | Glass glue gun | pc | glass glue extruder | ||
| 8 | Fiber-mesh cloth | m2 | Basic level processing before emulsioni paint | ||
| 9 | Pointing agent | pc | Jointing for the wall,floor and pointing | ||
| 10 | 801glue | barrel | the flying powder ,Latex Paint for single time | ||
| 11 |
rough ground (wooden keel) |
pc | corner fixed parts for gypsum board ceiling | ||
| 12 | Iron nail | KG | corner fixed parts for gypsum board ceiling | ||
| 13 | waterproof paint | barrel |
waterproof processing for the wall and floor(in bathroom) (paint 300mm high for walls) |
||
