Product Details:
Payment & Shipping Terms:
|
| Raw Material: | EPS, Sand/fly Ash, Cement, Additives | Size (L*W*T): | 2270mmx610mmx60mm(75,60,100,120,150) |
|---|---|---|---|
| Sound Insulation: | 46dB | Fireproof: | 240 Minutes – Class A |
| Anchorage Load: | 50kg | Certification: | ISO/BV/CE/ |
| Waterproof: | Good |
Thermal Insulation Fireproof Soundproof Wall Sandwich panel For Real Estate Buildings
1 . Description:
Lightweight compound sandwich wall panel is a kind of green building material instead of tradditional brick,red brick,clay solid brick,air brick,color-coated steel sandwich board,gypsum blocak and so on .
It can widely be applied to wall materials of various high and low building, such as: bank, office building, hospital, school, hotel, mall, amusement hall, active barrack, old house reconstruction, residence and workshop .
2 . Size of Sandwich wall Panel
Name | Size(L*W*T)mm | Weight (kg/m2) | Packing(pcs/m2 20’GP) | Application |
EPS Cement sandwich wall panel | 2270x610x60 | 45-48 | 315 pcs /436 m2 | Roof, interior wall |
2270x610x75 | 50-53 | 252pcs / 349 m2 | Interior wall | |
2270x610x90 | 55-58 | 207pcs / 287 m2 | Interior/exterior wall | |
2270x610x100 | 60-65 | 189pcs / 262 m2 | Interior/exterior wall | |
2270x610x120 | 65-75 | 153pcs / 212 m2 | Exterior wall | |
2270x610x150 | 80-90 | 126pcs / 175 m2 | Exterior wall |
3 . Usage : Interior and exterior wall,roof ceiling and floor .
4 . Advantages of Sandwich wall panel
Energy-saving
Light weight
Sound insulation
Environmental protection
Most area-saving
Most waterproof and dampproof
Most fire-proof:
Most sound-insulation
Best hanging force
Most anti-seismic and impact resistance
Largest span and height thin webbed wall
Most civilized, environmental, high efficiency construction.
5 . Technical Data:
Technology index | Metal frame and plaster boad | VJ EPS Panel | GRC Board | Gypsum block |
Weight | 20kg/m2 | 35kg/m2(60mm thickness) | 40kg/m2 | 45kg/m2 |
Sound insulation | Almost no | excellent,46dB | normal | poor |
Waterproof | poor | excellent | normal | poor |
Heat insulation | no | excellent | normal | normal |
Anti-impact capacity/Hanging force | no | high impact single hanging force is 50KGS | can impact,good hanging force | can impact,normal hanging force |
Decoration difficulty | hard,with limiations | easy and without any limiations | General difficulty | General difficulty |
Wall thickness | 91mm | 60mm,increased interior space | 60mm | 75mm |
Useful life | 2-3 years | 60-70 years | 20-30 years | 15-20 years |
Material secondary use | no | 80% can be used | some available | almost no |
Construction efficiency | faster | fast | faster | faster |
6 . FAQ:
1 ). How many years your company has been in this field?
VANJOIN: More than 10 years of manufacturing EPS concrete sandwich wall panel,
now we are TOP 1 In middle of China, and among top 2 in china in this field .
2 ).Where is your main market of VANJOIN?
VANJOIN: Main market Asia, South America, Africa,South East Asia is our largest market,
Mid East is our second largest market.
3 ). Exporting details :
VANJOIN: Loading & shipping 400 x 20 GP each month.
4 ). More information of VANJOIN factory?
VANJOIN: land area 30,000 m2 machines, full-automatic production line Productivity:
2,000,000 m2 wall panel per year.
5 ). How could i get the samples?
VANJOIN: We send you the free samples, catalogues, CD, but the Express charge is required, if you have the DHL, TNT, UPS, FedEx account, this is the best.
If not, you can transfer money to our Western Union, then we will send you.
