Product Details:
Payment & Shipping Terms:
|
| Face Board: | Calcium Silicate Board | Core Materials: | EPS, Cement, Sand, Additives |
|---|---|---|---|
| Standard Thickness: | 60mm, 75mm, 90mm, 100mm, 120mm, 150mm | Application: | Interior Wall, Exterior Wall, Flooring, Roofing |
| Sound Insulation: | 46dB | Lifespan: | 70 Years |
| Advantages: | Fast Construction, Green |
Household Kitchen Expandable Polystyrene EPS Composite Board Non-asbestos
| Type | EPS Cement Sandwich Panel |
| Composition |
1. Face boards: calcium silicate board 5mm thickness 2. Core materials: eps foam, cement, sand, additives |
| Standard Size |
Length 2270mm Width 610mm, Thickness: 60mm,75mm,90mm,100mm,120mm,150mm |
| Application | Exterior and interior wall, floor and roof for various houses and buildings |
| Main Structure of House | Concrete or steel structure |
| Supply ability | 2,000,000m2 per year |
| Delivery time | Within 7 days after receiving prepayment. |
| Payment terms | T/T, L/C |
| Packing Details | 1. Standard exporting packing, good pallet+corner protective paper+packing belt+plastic thin film 3. Packing size: 2270*610*1000mm 4.Loading: 18 pallets per 20' container |
| Samples | Free samples are available |
| Certificates | CE,ISO,,BV, with test reports and patents |
Brief Introduction
Vanjoin lightweight prefabricated sandwich panels is a NEW kind of energy saving green building construction material.
It is mainly used for interior wall and exterior wall, and also can be used for roofing and flooring.
Composition
Face board: 5mm Calcium Silicon Board
Inner materials: eps foam, cement, sand
Usage
Specification
| Length | Width | Thickness | Application |
| 2270mm | 610mm | 60mm | Roof |
| 75mm | Interior wall | ||
| 90mm | Interior / Exterior wall | ||
| 100mm | Interior / Exterior wall | ||
| 120mm | Exterior wall | ||
| 150mm | Exterior wall |
Main Features
| 1. Lightweight | 1 person can carry panel easily, 1/6 of traditional brick |
| 2. Eco-friendly | 100% non-asbestos |
| 3. Fast Construction | 3 workers can install 60-80m2 per day |
| 4. Durable and Long Lifespan | 60-70 years |
| 5. Sound Insulation | 46 dB |
| 6. Windproof | 65m/s |
| 7. Fireproof | 4 hours under 1000 degree fire |
| 8. Anti-earthquake | Grade 8-9 |
| 9. Best hanging force | Single point is 50kg;Embedded hanging force 150kg |
| 10. Weight capacity | 650KG / m3 |
| 11.Space saving | Save 4.26m2 per 100 m2 area |
| 12.Anti-seimisic / Earthquake | Class 7-8 |
| 13. Easy decoration | Convenient for pipeline embeded |
Packing Details
|
Packing Details |
1. Standard exporting packing | wrapped with plastic thin film,wedge protect & good pallet | |
| 2. Packing size: | 1500-3000*610*1000mm | ||
| 3. Loading | 18 pallets per 20' container | ||
